Test and Validate

The validator API endpoint allows you to test your transform with sample data. It will interpret both the transform and data and output how Hydrolix will parse and enrich it.

Example:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
curl -s \
     -H 'content-type: application/json' \
     -H 'x-hdx-table: sample_project.sample_table' \
     -H 'x-hdx-test: true' \
     https://$host/validator \
     --data-binary '{
  "transform": {
    "settings": {
      "sql_transform": "SELECT primary, -some_int32 AS `some_int32`, COALESCE(some_other_int32, 789) AS `some_other_int32` FROM {STREAM}",
      "output_columns": [
        {
          "name": "primary",
          "datatype": {
            "type": "datetime",
            "format": "02/01/2006 15:04:05",
            "primary": true
          }
        },
        {
          "name": "some_int32",
          "datatype": {
            "type": "int32"
          }
        },
        {
          "name": "some_other_int32",
          "datatype": {
            "type": "int32"
          }
        }
      ]
    }
  },
  "data": [
    {"primary": "14/06/2022 13:06:47", "some_int32": 99, "some_other_int32": 1234},
    {"primary": "14/06/2022 13:06:48", "some_int32": 99},
    {"primary": "14/06/2022 13:06:49", "some_int32": 123},
    {"primary": "14/06/2022 13:06:50", "some_int32": 456}
  ]
}'

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
HTTP/1.1 200 OK
Content-Type: application/json; charset=utf-8
Date: Mon, 18 Jul 2022 08:49:37 GMT
Connection: close
Transfer-Encoding: chunked

{
  "code": 200,
  "message": "success",
  "project": {
    "name": "",
    "uuid": ""
  },
  "table": {
    "name": "",
    "uuid": ""
  },
  "transform": {
    "name": "",
    "uuid": ""
  },
  "parsed": [
    [
      {
        "name": "primary",
        "datatype": "datetime",
        "value": "2022-06-14 13:06:47"
      },
      {
        "name": "some_int32",
        "datatype": "int32",
        "value": 99
      },
      {
        "name": "some_other_int32",
        "datatype": "int32",
        "value": 1234
      }
    ],
    [
      {
        "name": "primary",
        "datatype": "datetime",
        "value": "2022-06-14 13:06:48"
      },
      {
        "name": "some_int32",
        "datatype": "int32",
        "value": 99
      },
      {
        "name": "some_other_int32",
        "datatype": "int32",
        "value": null
      }
    ],
    [
      {
        "name": "primary",
        "datatype": "datetime",
        "value": "2022-06-14 13:06:49"
      },
      {
        "name": "some_int32",
        "datatype": "int32",
        "value": 123
      },
      {
        "name": "some_other_int32",
        "datatype": "int32",
        "value": null
      }
    ],
    [
      {
        "name": "primary",
        "datatype": "datetime",
        "value": "2022-06-14 13:06:50"
      },
      {
        "name": "some_int32",
        "datatype": "int32",
        "value": 456
      },
      {
        "name": "some_other_int32",
        "datatype": "int32",
        "value": null
      }
    ]
  ],
  "partition": "",
  "bytes": 0,
  "rows": 0,
  "columns": 0,
  "min_timestamp": 0,
  "max_timestamp": 0,
  "mem_size": 0,
  "shard_key_hash": "",
  "test_response": {
    "data": [
      [
        "2022-06-14 13:06:47",
        -99,
        1234
      ],
      [
        "2022-06-14 13:06:48",
        -99,
        789
      ],
      [
        "2022-06-14 13:06:49",
        -123,
        789
      ],
      [
        "2022-06-14 13:06:50",
        -456,
        789
      ]
    ],
    "meta": [
      {
        "name": "primary",
        "type": "DateTime"
      },
      {
        "name": "some_int32",
        "type": "Nullable(Int32)"
      },
      {
        "name": "some_other_int32",
        "type": "Nullable(Int32)"
      }
    ],
    "rows": 4,
    "statistics": {
      "bytes_read": 56,
      "elapsed": 0.000934846,
      "rows_read": 4
    }
  },
  "indexing_sql": "SELECT `primary`::DateTime as `primary`,`some_int32`::Nullable(Int32) as `some_int32`,`some_other_int32`::Nullable(Int32) as `some_other_int32` FROM (SELECT `primary`::DateTime as `primary`,`some_int32`::Nullable(Int32) as `some_int32`,`some_other_int32`::Nullable(Int32) as `some_other_int32` FROM (SELECT primary, -some_int32 AS `some_int32`, COALESCE(some_other_int32, 789) AS `some_other_int32` FROM file('e81c5d8c-4804-4dd0-812d-e331e3bad1c0.json', 'JSONCompactEachRow', '`primary` DateTime,`some_int32` Nullable(Int32),`some_other_int32` Nullable(Int32)'))) FORMAT JSONCompact SETTINGS hdx_format_work_dir='', hdx_format_sort_keys='', hdx_format_json_schema='[{\"name\":\"primary\",\"datatype\":{\"type\":\"datetime\",\"primary\":true,\"format\":\"%F %T\",\"resolution\":\"s\"}},{\"name\":\"some_int32\",\"datatype\":{\"type\":\"int32\"}},{\"name\":\"some_other_int32\",\"datatype\":{\"type\":\"int32\"}}]', hdx_format_metadata='{\"project\":{\"id\":\"bb8c48f4-7ac2-4de7-99c7-a3cbc195b265\",\"name\":\"sample_project\",\"revision\":5},\"table\":{\"id\":\"c21408ad-7b48-49e8-88c7-bdd8e0f716f1\",\"name\":\"sample_table\",\"revision\":4},\"transforms\":[{\"id\":\"\",\"name\":\"\"}]}', max_ast_elements=100000, max_expanded_ast_elements=100000",
  "intermediate_data": {
    "/var/lib/indexer/e81c5d8c-4804-4dd0-812d-e331e3bad1c0.json": "WyIyMDIyLTA2LTE0IDEzOjA2OjQ3Iiw5OSwxMjM0XQpbIjIwMjItMDYtMTQgMTM6MDY6NDgiLDk5LG51bGxdClsiMjAyMi0wNi0xNCAxMzowNjo0OSIsMTIzLG51bGxdClsiMjAyMi0wNi0xNCAxMzowNjo1MCIsNDU2LG51bGxdCg=="
  }
}

The intermediate_data is the base64 JSON-encoded interpretation of the data, and the indexing SQL is what'sused as SQL statement to generate Hydrolix partitions based the data.

If there are any errors from any component, they'll be included in the response. For example, if the indexer isn't able to parse the timestamp or the format, it will output an error.

Delimiters in CSV format⚓︎

When sending in a transform in CSV format, make sure escaped characters are specified as an ASCII character code rather than the character. For example, to specify a tab delimiter, use the ASCII equivalent. Rather than:

1
2
3
4
"format_details": {
  "delimiter": "\t",
  ...
}

Use the ASCII equivalent:

1
2
3
4
"format_details": {
  "delimiter": 9,
  ...
}

This applies to the sample transform formats found in Hydrolix's sample repository. While the CSV formats contained there will work with the Transforms API, some of them must be modified to work with this endpoint.

Use the catch_all Feature⚓︎

The catch_all feature allows you to see the shape of your data before you've applied a transform to it. For example, below is a transform with a mapping catchall, followed by three lines of sample data:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
POST https://$host/validator
Content-Type: application/json
x-hdx-table: sample_project.sample_table
x-hdx-test: true

{
  "transform": {
    "name": "demo",
    "type": "json",
    "settings": {
      "is_default": true,
      "output_columns": [
        {
          "name": "date",
          "datatype": {
            "type": "datetime",
            "format": "2006-01-01",
            "resolution": "seconds",
            "primary": true
          }
        },
        {
          "name": "catchall",
          "datatype": {
            "type": "map",
            "elements": [
              {
                "type": "string"
              },
              {
                "type": "string"
              }
            ],
            "catch_all": true
          }
        }
      ],
      "compression": "none",
      "format_details": {
        "flattening": {
          "active": true,
          "depth": 1,
          "map_flattening_strategy": {
            "left": "."
          }
        }
      }
    }
  },
  "data": [
    {
      "timestamp": "2022-06-13 06:03:05.579 +00:00",
      "component": "query_executor",
      "level": "info",
      "user": "anonymous",
      "duration": 552,
      "query": "'select version()'",
      "message": "comment='' admin_comment=''"
    },
    {
      "timestamp": "2022-06-13 06:03:06.078 +00:00",
      "component": "query_executor",
      "level": "info",
      "user": "anonymous",
      "duration": 552,
      "query": "'select version()'",
      "message": "comment='' admin_comment=''"
    },
    {
      "timestamp": "2022-06-13 06:03:06.086 +00:00",
      "component": "query_executor",
      "level": "info",
      "message": "user=anonymous duration_ms=0 comment='' admin_comment='' query='select version()'"
    }
  ]
}

Here any JSON key value in the sample data will be interpreted as a map and put in the catchall column:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
"parsed": [
    [
      {
        "name": "date",
        "datatype": "datetime",
        "value": null
      },
      {
        "name": "catchall",
        "datatype": "map",
        "value": {
          "component": "query_executor",
          "duration": "552",
          "level": "info",
          "message": "comment='' admin_comment=''",
          "query": "'select version()'",
          "timestamp": "2022-06-13 06:03:05.579 +00:00",
          "user": "anonymous"
        }
      }
    ]

Use the catch_rejects Feature⚓︎

The catch_rejects attribute adds an extra filter to a transform. Invalid ingested data is added to a discrete column, while valid data is ingested as expected.

For example, assume you have a table with two columns.

Name Type
primary_column DateTime
uint_column Uint32

An example transform for this would look like the following:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
[
  {
    "name": "primary_column",
    "datatype": {
      "type": "epoch",
      "primary": true,
      "format": "s"
    }
  },
  {
    "name": "uint_column",
    "datatype": {
      "type": "uint32"
    }
  }
]

If your ingested data contains fields with invalid values, these will be rejected entirely. The result may be a partial success, and return an error message.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
{
  "code": 207,
  "message": {
    "success_count": 2,
    "errors": [
      "(column {\"name\":\"uint_column\",\"datatype\":{\"type\":\"uint32\",\"source\":{\"from_input_index\":1,\"from_input_fields\":[\"uint_column\"]}},\"position\":1} data -1 (json.Number)): value of unsigned column is negative -1",
      "(column {\"name\":\"uint_column\",\"datatype\":{\"type\":\"uint32\",\"source\":{\"from_input_index\":1,\"from_input_fields\":[\"uint_column\"]}},\"position\":1} data -2 (json.Number)): value of unsigned column is negative -2"
    ]
  }
}

You can use catch_rejects to separate the invalid values and pass the correct data by adding the attribute to the transform. This must be a string>string map.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
[
  {
    "name": "primary_column",
    "datatype": {
      "type": "epoch",
      "primary": true,
      "format": "s"
    }
  },
  {
    "name": "rejected_data",
    "datatype": {
      "type": "map",
      "catch_rejects": true,
      "elements": [
        {
          "type": "string"
        },
        {
          "type": "string"
        }
      ]
    }
  },
  {
    "name": "uint_column",
    "datatype": {
      "type": "uint32"
    }
  }
]

Ingest the same data again, and you'll have three columns. The rejected_data column shows the invalid data, and the other two columns are populated with good data or null values.

primary_column rejected_data uint_column
2024-12-12 18:10:14 UTC {'uint_column': '-2'} null
2024-12-12 18:10:14 UTC {} 1
2024-12-12 18:10:14 UTC {'uint_column': '-1'} null
2024-12-12 18:10:14 UTC {} 2
