Kibana Manual Installation

This detailed guide will show you how to set up Kibana, Kibana Gateway, and ElasticSearch yourself. Alternatively, Hydrolix comes with these services pre-configured. See Kibana Automatic Installation for more details.

What is Kibana Gateway?

Kibana Gateway is a lightweight database proxy that enables interoperability between a front end such as Kibana and multiple back end datastores such as Hydrolix and ElasticSearch. It provides this interoperability by acting as a SQL translation layer that entirely decouples your dashboarding and ingestion layers from your datastore(s). Two compelling use cases for Kibana Gateway are:

• Using it as a translation layer for queries during a datastore platform migration. Doing so can remove the need to alter application code or refactor SQL queries to maintain datastore compatibility during the migration.
• Using Kibana with Hydrolix instead of ElasticSearch
• Easy, simultaneous querying of multiple back end datastores.

Installation Guide for Existing Environments

If you have an existing system in which you want to incorporate Kibana Gateway and Hydrolix, there are various scenarios and their instructions described in the Kibana Gateway installation guide.

Installation Guide from Scratch

In the following tutorial, we will be standing up a Kibana front end, a Kibana Gateway query and ingest routing and translation layer, and an ElasticSearch back end datastore. This setup will be integrated with your existing Hydrolix cluster and can be used to simulate a multi-datastore architecture. Ingest will be routed to ElasticSearch, while queries are routed to both Hydrolix and ElasticSearch.

Before You Begin

You will need:

1. A running Hydrolix deployment. Follow the instructions for your preferred cloud vendor if you have yet to deploy Hydrolix. From your running Hydrolix cluster, you will need the following information:

Item	Description	Example values
Hydrolix URL + ClickHouse port	This is the URL of your Hydrolix cluster appended with the ClickHouse Native protocol SSL/TLS port.	https://{myhostname}.hydrolix.live:9440
Project name	The project name in Hydrolix which will correspond to the database name configured for Kibana Gateway. It is the logical namespace for your tables. Instructions for creating a project can be followed here.	Name: project_name
Table name(s)	You will need the names of the tables you want to expose within the Kibana interface via Kibana Gateway configuration. Instructions for creating a table can be followed here .	Name:table_name0, table_name1
Credentials	The username and password for your Hydrolix cluster account.	username: user@domain.com password: correcthorsebatterystaple

1. Git. You can install the git CLI or Github Desktop.
2. Docker v20.10 or higher. You can install Docker Desktop here.

Configure the Containers With Docker Compose

The following steps are similar to Kibana Gateway quick start demo setup for deploying Kibana and ElasticSearch. You will be using the Docker Compose file from those directions but omitting the ClickHouse server and replacing it with your running Hydrolix cluster.

We will also be following the Hydrolix-specific instructions to configure Kibana Gateway to route queries to your Hydrolix cluster rather than a ClickHouse server.

Ingest Currently Not Supported

Kibana Gateway currently supports routing queries to Hydrolix. Ingest to Hydrolix using Kibana Gateway is not supported.

Open a command-line terminal and execute the following:

• Clone Kibana Gateway repository with git clone https://github.com/QuesmaOrg/quesma.git.
• Navigate to the working directory containing the Docker Compose file with cd quesma/examples/kibana-sample-data.
• Edit the docker-compose.yml in this directory and remove or comment out the clickhouse container as the following example shows:

```yaml docker-compose.yml services: {...} #clickhouse: # user: 'default', no password # image: clickhouse/clickhouse-server:23.12.2.59-alpine # ports: # - "8123:8123" # - "9000:9000" # healthcheck: # test: wget --no-verbose --tries=1 --spider http://clickhouse:8123/ping || exit 1 # interval: 1s # timeout: 1s # start_period: 1m

Be sure to save your changes!

We're not yet ready to execute this Docker Compose file. However, with these steps completed, executing the file would locally deploy:

- A **Quesma** container (which is not yet configured to communicate with your Hydrolix cluster)
- An **ElasticSearch** datastore and query engine
- A **Kibana** data visualization interface
- **Three sample data sets** that load data into ElasticSearch via two containers (`log-generator` and `kibana-sidecar`)

## Configure Kibana Gateway

In this section, we will configure Kibana Gateway to route queries to your running Hydrolix cluster and we will remove any references to the ClickHouse cluster. You can read more about configuring Kibana Gateway in the [Configuration Primer](https://eap.quesma.com/config-primer).

Back in the command line, navigate into the directory containing the Kibana Gateway config with `cd quesma/config`. Apply the following changes to `local-dev.yaml`:

1. Add your license key to the top with:

FIXME: See DOC-1117 for thread: The manual use of Kibana Gateway is not a supported installation now that Hydrolix has acquired the software. See the automatic installation page.
FIXME: If we decide to (re-)publish this content in the future, we must test how the software handles licenses now that Hydrolix owns the product.

```yaml local-dev.yaml
licenseKey: {your-license-key}

1. Add the following to backendConnectors:

```yaml local-dev.yaml - name: my-hydrolix-instance type: hydrolix config: url: https://{hydrolix_host}:9440 user: {username} password: {password} database: {hydrolix_project_name}

Fill in your Hydrolix host, username, password, and database name. This provides connection information to Kibana Gateway so it can communicate with your running Hydrolix cluster. The name you specify for the Hydrolix backend connector is strictly for referencing it within this configuration file. It does not have to be the name of your running Hydrolix cluster.

!!! note "Determining your database name"
    The project name in Hydrolix corresponds to the database name for Kibana Gateway.

1. Remove or comment out ClickHouse from `backendConnectors`:

```yaml local-dev.yaml
backendConnectors:
{...}
  #- name: my-clickhouse-data-source
  #  type: clickhouse-os
  #  config:
  #    url: "clickhouse://clickhouse:9000"
  #    adminUrl: "http://localhost:8123/play"

1. In the pipelines section, replace mentions of my-clickhouse-data-source with my-hydrolix-instance. This configuration change ensures that Kibana Gateway will route queries to both the Hydrolix and ElasticSearch back ends. For consistency, you can also rename the pipelines:

2. my-pipeline-elasticsearch-query-clickhouse -> my-pipeline-elasticsearch-query-hydrolix

3. my-pipeline-elasticsearch-ingest-to-clickhouse -> my-pipeline-elasticsearch-ingest-to-elastic.

4. Replace all other instances of my-clickhouse-data-source with my-minimal-elasticsearch. There should be six altogether configured for the following indices:

5. kibana_sample_data_ecommerce

6. kibana_sample_data_flights
7. logs-generic-default

These indices are specified for the following processors:

• my-query-processor
• my-ingest-processor

We are modifying this configuration so Kibana Gateway knows to ingest data into and query those indices solely within ElasticSearch.

1. Add your Hydrolix table(s) to processors.my-query-processor.config.indexes with target my-hydrolix-instance. If you were to use the tables table_name0 and table_name1 from above, you would configure them like so:

```yaml local-dev.yaml processors: - name: my-query-processor type: quesma-v1-processor-query config: indexes: table_name0: target: [ my-hydrolix-instance ] table_name1: target: [ my-hydrolix-instance ]

This tells Kibana Gateway to query the data stored in those tables in your Hydrolix cluster.

Save your changes.

## Deploy Kibana, ElasticSearch, and Kibana Gateway

Run the following command to deploy your containers locally:

```shell
docker compose -f docker-compose.yml up

Verify Functionality

Kibana

The Kibana UI should be available at localhost:5601:

Kibana Gateway

The Kibana Gateway admin panel should be accessible at localhost:9999:

Note that the admin panel does not require authentication by default and can be disabled in the docker-compose.yaml by commenting out or removing port forwarding for port 9999:

services:
  quesma:
    ports:
      #- "9999:9999"
      - "9200:8080"

You should also be able to view your tables, including Hydrolix tables, at localhost:9999/schemas.

The quesma container logs to stderr.

If you run into problems with your quesma container and want to search its logs, be sure to combine both stderr and stdout to the stdout stream with 2>&1. For example:

docker logs {quesma_container_id} 2>&1 | grep "ERROR"

Otherwise, grep will not function on the logs from the quesma container.

Create a Data View in Kibana for your Hydrolix Data

In order to view your Hydrolix tables in Kibana, you need to create Data Views for tables (indexes). Follow these directions to create one.
